Seasonic Vertex 1200W (PX-1200) Platinum Fully Modular PSU ATX 3.0
🔥 Winter Deal: Save 10% + Free Shipping – This Week Only! Use Code STAYLIT10 at Checkout
Order in the next 3 hours 2 minutes to get it between -
The Seasonic PRIME TX-1300 1300W Titanium ATX 3.0 Fully Modular PSU is a high-end power supply unit (PSU) designed for enthusiast-grade gaming PCs, workstations, and power-hungry systems. It delivers 1300 watts of stable power, meeting 80 PLUS Titanium efficiency standards for maximum energy savings and performance.
Key Features:
🔹 1300W Power Output – Ideal for high-performance gaming rigs, overclocked systems, and workstations.
🔹 80 PLUS Titanium Certification – Industry-leading efficiency (94%+), reducing energy waste and heat.
🔹 ATX 3.0 & PCIe 5.0 Ready – Supports modern GPUs like NVIDIA RTX 40-series with native 12VHPWR (16-pin) cable.
🔹 Fully Modular Design – Only connect the cables you need, ensuring better cable management and airflow.
🔹 High-Quality Japanese Capacitors – Provides exceptional durability and reliability.
🔹 Premium Hybrid Fan Control – Ultra-quiet 135mm Fluid Dynamic Bearing (FDB) fan for silent operation.
🔹 Robust Protection Features – Over-voltage, over-power, over-temperature, and short-circuit protection.
🔹 12-Year Warranty – One of the longest warranties in the industry, ensuring long-term reliability.
Who Is It For?
✅ Gamers with high-end GPUs (RTX 4090, RX 7900 XTX, etc.)
✅ Overclockers pushing CPUs and GPUs to the limit
✅ Workstation users running multiple GPUs, AI workloads, or rendering
✅ PC builders looking for best-in-class efficiency, reliability, and quiet operation
FEATURE SUMMARY
- Super-High Efficiency, 80 PLUS® Platinum Certified
- Fully Modular
- ATX 3.0 and 16-Pin PCIe Gen 5 Cable (12VHPWR)
- Top-Quality 135 mm Fluid Dynamic Bearing Fan
- Premium Hybrid Fan Control
- Tight Voltage Regulation (12V, 5V and 3.3V) [± 3%]
- Gold Plated High Current Terminal (MB, CPU and PCIe)
| Technical Specifications | ||
| 80PLUS® | Platinum | |
| Cybenetics Efficiency Level | TBA | |
| Cybenetics Noise Level | TBA | |
| Form Factor | Intel ATX 12V | |
| Dimensions | 160 mm (L) x 150 mm (W) x 86 mm (H) | |
| Fan Information | Fan Size | 135 mm |
| Fan Control | Premium Hybrid Fan Control | |
| Fan Bearing | Fluid Dynamic Bearing | |
| Life Expectancy | 50,000 hours at 40 °C, 15 % - 65 % RH | |
| Cable Information | Modularity | Fully Modular |
| Cable type | Flat black cables | |
| Electrical Features | Operating Temperature | 0 - 50 °C (derating from 100 % to 80 % from 40 °C to 50 °C) |
| MTBF @ 25 °C, excl. fan | 150,000 hours | |
| AC Input | Full Range | |
| Protection | OPP, OVP, UVP, OCP, OTP, SCP | |
| Safety and Environmental | Safety and EMC | cTUVus, TUV, CB, CCC, BSMI, EAC, CE |
| Environmental Compliance | Energy Star, RoHS, WEEE, ErP Lot 6, REACH | |
| Warranty | 10 Years | |
|
Power Output
|
||||||
|---|---|---|---|---|---|---|
| AC Input | Voltage: 100 V - 240 V | |||||
| Current: 15 - 7.5 A | ||||||
| Frequency: 50 Hz - 60 Hz | ||||||
| DC Output | Rail | +3.3 V | +5 V | +12 V | -12 V | +5 VSB |
| Maximum Power | 25 A | 25 A | 100 A | 0.3 A | 3 A | |
| 125 W | 1200 W | 3.6 W | 15 W | |||
| Total Continuous Power | 1200 W | |||||
